Part number: | 11-03774 |
The CB Series are dry charged lead acid batteries. Indefinite shelf life until activated with electrolyte. The CB24-11M features a manifold to facilitate direct replacement of the originally designed manifold vented battery. Patented copper alloy terminals for low resistance without corrosion. High impact polypropylene container and cover Dry charged CB batteries WITHOUT electrolyte ship as non-hazardous material - HAZMAT EXEMPT NOTE: This aircraft battery is not designed or intended for turbine aircraft engine starting applications. Warranty coverage applies to reciprocating aircraft engine starting, and standby / essential power installations. |
Battery Type |
Voltage |
Ampere Hours |
Max. Weight |
Gill/Rebat Equivalent |
Our P/N |
Battery Diagram PDF |
CB24-11M w/o Acid |
24 |
10 |
28 lbs. |
G243/-- |
11-03774
|
|
CB24-11M with Acid |
24 |
10 |
28 lbs. |
G243/-- |
11-03773
|
Unit | EA |
Hazardous | No |
Oversize | No |
Weight | 11.793 kg |
Manufacturer | Concorde Battery |
