O-Ring MS28775-015
| Part number: | 05-04646 |
1.86 EUR
incl. 19% VAT, excl. shipping
Will ship today if you order before 11:00. This information is valid for up to 5 EA
Available Quantities:
| Today: | 5 EA |
| In 11 days: | 472 EA |
Description:
O-rings give effective sealing over wide ranges of pressure, temperature, and movement, with the advantage of sealing pressure in both directions and reducing friction and wear on moving parts. The use of O-rings as gaskets or static seals permits metal-to-metal contact and allows almost unlimited pressures under extreme vibration.
All 0-rings should be lubricated before installation and constant lubrication should be provided for running seals to avoid excessive wear. Avoid sharp edges, threads, and cross-drilled ports over or through which rings must be installed. AN6227B and AN6230B 0-rings are manufactured to Spec. MIL-P 25732 for use in hydraulic systems using MIL-0-5606 hydraulic oils. MS28775 O-rings meet Spec. MIL-P- 5510A and are suitable for MIL-0-5606 hydraulic fluid at 160 F.
| PN | MS Equivalent | Width | ID | OD |
| AN6227B-1 | MS28775-6 | 1/16 | 1/8 | 1/4 |
| AN6227B-2 | MS28775-7 | 1/16 | 5/32 | 9/32 |
| AN6227B-3 | MS28775-8 | 1/16 | 3/16 | 5/16 |
| AN6227B-4 | MS28775-9 | 1/16 | 7/32 | 11/32 |
| AN6227B-5 | MS28775-10 | 1/16 | 1/4 | 3/8 |
| AN6227B-6 | MS28775-11 | 1/16 | 5/16 | 7/16 |
| AN6227B-7 | MS28775-12 | 1/16 | 3/8 | 1/2 |
| 05-04892 | MS28775-13 | 1/16 | 7/16 | 9/16 |
| 05-04893 | MS28775-14 | 1/16 | 1/2 | 5/8 |
| 05-04646 | MS28775-015 | 1/16 | 9/16 | 11/16 |
| 05-04894 | MS28775-16 | 1/16 | 5/8 | 3/14 |
| 05-04895 | MS28775-17 | 1/16 | 11/16 | 13/16 |
| 05-04896 | MS28775-18 | 1/16 | 3/4 | 7/8 |
| 05-04897 | MS28775-19 | 1/16 | 13/16 | 15/16 |
| 05-04898 | MS28775-20 | 1/16 | 7/8 | 1 |
| 05-04899 | MS28775-21 | 1/16 | 11/16 | 1-1/16 |
| MS28775-022 | MS28775-022 | 1/16 | 1 | 1-1/8 |
| 05-04901 | MS28775-23 | 1/16 | 1-1/16 | 1-3/16 |
| 05-04902 | MS28775-24 | 1/16 | 1-1/8 | 1-1/4 |
| 05-04903 | MS28775-25 | 1/16 | 1-3/16 | 1-5/16 |
| 05-04911 | MS28775-026 | 1/16 | 1-1/4 | 1-3/8 |
| 05-04912 | MS28775-027 | 1/16 | 1-5/16 | 1-7/16 |
| 05-04913 | MS28775-028 | 1/16 | 1-3/8 | 1-1/2 |
| AN6227B-8 | MS28775-110 | 3/32 | 3/8 | 9/16 |
| AN6227B-9 | MS28775-111 | 3/32 | 7/16 | 5/8 |
| AN6227B-10 | MS28775-112 | 3/32 | 1/2 | 11/16 |
| AN6227B-11 | MS28775-113 | 3/32 | 9/16 | 3/4 |
| AN6227B-12 | MS28775-114 | 3/32 | 5/8 | 13/16 |
| AN6227B-13 | MS28775-115 | 3/32 | 11/16 | 7/8 |
| AN6227B-14 | MS28775-116 | 3/32 | 3/4 | 15/16 |
| 05-04914 | MS28775-117 | 3/32 | 13/16 | 1 |
| MS28775-118 | MS28775-118 | 3/32 | 7/8 | 1-1/16 |
| 05-04915 | MS28775-119 | 3/32 | 15/16 | 1-1/8 |
| 05-04916 | MS28775-120 | 3/32 | 1 | 1-3/16 |
| 05-04917 | MS28775-121 | 3/32 | 1-1/16 | 1-1/4 |
| 05-04918 | MS28775-122 | 3/32 | 1-1/8 | 1-5/16 |
| 05-04919 | MS28775-123 | 3/32 | 1-3/16 | 1-3/8 |
| 05-04920 | MS28775-124 | 3/32 | 1-1/4 | 1-7/16 |
| 05-04921 | MS28775-125 | 3/32 | 1-5/16 | 1-1/2 |
| 05-04922 | MS28775-126 | 3/32 | 1-3/8 | 1-9/16 |
| 05-04923 | MS28775-127 | 3/32 | 1-7/16 | 1-5/8 |
| 05-04924 | MS28775-128 | 3/32 | 1-1/2 | 1-11/16 |
| 05-04925 | MS28775-129 | 3/32 | 1-9/16 | 1-3/4 |
| 05-04926 | MS28775-130 | 3/32 | 1-5/8 | 1-13/16 |
| 05-04927 | MS28775-131 | 3/32 | 1-11/16 | 1-7/8 |
| 05-00850 | MS28775-132 | 3/32 | 1-3/4 | 1-15/16 |
| 05-05142 | MS28775-134 | 3/32 | 1-7/8 | 2-1/16 |
| 05-05143 | MS28775-135 | 3/32 | 1-15/16 | 2-1/8 |
| 05-05144 | MS28775-136 | 3/32 | 2 | 2-3/16 |
| 05-05145 | MS28775-137 | 3/32 | 2-1/16 | 2-1/4 |
| 05-05146 | MS28775-138 | 3/32 | 2-1/8 | 2-5/16 |
| 05-05147 | MS28775-139 | 3/32 | 2-3/16 | 2-3/8 |
| 05-05148 | MS28775-140 | 3/32 | 2-1/4 | 2-7/16 |
| 05-05149 | MS28775-141 | 3/32 | 2-5/16 | 2-1/2 |
| 05-05150 | MS28775-142 | 3/32 | 2-3/8 | 2-9/16 |
| 05-05151 | MS28775-143 | 3-32 | 2-7/16 | 2-5/8 |
| 05-05152 | MS28775-144 | 3/32 | 2-1/2 | 2-11/16 |
| 05-05153 | MS28775-145 | 3/32 | 2-9/16 | 2-3/4 |
| 05-05154 | MS28775-146 | 3/32 | 2-5/8 | 2-13/16 |
| 05-05155 | MS28775-147 | 3/32 | 2-11/16 | 2-7/8 |
| 05-05156 | MS28775-148 | 3/32 | 2-3/4 | 2-15/16 |
| 05-05157 | MS28775-149 | 3/32 | 2-13/16 | 3 |
| AN6227B-15 | MS28775-210 | 1/8 | 3/4 | 1 |
| AN6227B-16 | MS28775-211 | 1/8 | 13/16 | 1-1/16 |
| AN6227B-17 | MS28775-212 | 1/8 | 7/8 | 1-1/8 |
| AN6227B-18 | MS28775-213 | 1/8 | 15/16 | 1-3/16 |
| AN6227B-19 | MS28775-214 | 1/8 | 1 | 1-1/4 |
| AN6227B-20 | MS28775-215 | 1/8 | 1-1/16 | 1-5/16 |
| AN6227B-21 | MS28775-216 | 1/8 | 1-1/8 | 1-3/8 |
| AN6227B-22 | MS28775-217 | 1/8 | 1-3/16 | 1-7/16 |
| AN6227B-23 | MS28775-218 | 1/8 | 1-1/4 | 1-1/2 |
| AN6227B-24 | MS28775-219 | 1/8 | 1-5/16 | 1-9/16 |
| AN6227B-25 | MS28775-220 | 1/8 | 1-3/8 | 1-5/8 |
| AN6227B-26 | MS28775-221 | 1/8 | 1-7/16 | 1-11/16 |
| AN6227B-27 | MS28775-222 | 1/8 | 1-1/2 | 1-3/4 |
| AN6230B-1 | MS28775-223 | 1/8 | 1-5/8 | 1-7/8 |
| AN6230B-2 | MS28775-224 | 1/8 | 1-3/4 | 2 |
| AN6230B-3 | MS28775-225 | 1/8 | 1-7/8 | 2-1/8 |
| AN6230B-4 | MS28775-226 | 1/8 | 2 | 2-1/4 |
| AN6230B-5 | MS28775-227 | 1/8 | 2-1/8 | 2-3/8 |
| AN6230B-6 | MS28775-228 | 1/8 | 2-1/4 | 2-1/2 |
| AN6230B-7 | MS28775-229 | 1/8 | 2-3/8 | 2-5/8 |
| AN6230B-8 | MS28775-230 | 1/8 | 2-1/2 | 2-3/4 |
| AN6230B-9 | MS28775-231 | 1/8 | 2-5/8 | 2-7/8 |
| AN6230B-10 | MS28775-232 | 1/8 | 2-3/4 | 3 |
| 05-01013 | MS28775-233 | 1/8 | 2-7/8 | 3-1/8 |
| 05-05158 | MS28775-236 | 1/8 | 3-1/4 | 3-1/2 |
| 05-05159 | MS28775-237 | 1/8 | 3-3/8 | 3-5/8 |
| 05-05160 | MS28775-238 | 1/8 | 3-1/2 | 3-3/4 |
| 05-05161 | MS28775-239 | 1/8 | 3-5/8 | 3-7/8 |
| 05-05162 | MS28775-240 | 1/8 | 3-3/4 | 4 |
| 05-05163 | MS28775-241 | 1/8 | 3-7/8 | 4-1/8 |
| 05-05164 | MS28775-242 | 1/8 | 4 | 4-1/4 |
| 05-05165 | MS28775-243 | 1/8 | 4-1/8 | 4-3/8 |
| 101-07200 | MS28775-244 | 1/8 | 4-1/4 | 4-1/2 |
| 05-05166 | MS28775-245 | 1/8 | 4-3/8 | 4-5/8 |
| 05-05167 | MS28775-246 | 1/8 | 4-1/2 | 4-3/4 |
| 05-05168 | MS28775-247 | 1/8 | 4-5/8 | 4-7/8 |
| AN6227B-28 | MS28775-325 | 3/16 | 1-1/2 | 1-7/8 |
| AN6227B-29 | MS28775-326 | 3/16 | 1-5/8 | 2 |
| AN6227B-30 | MS28775-327 | 3/16 | 1-3/4 | 2-1/8 |
| AN6227B-31 | MS28775-328 | 3/16 | 1-7/8 | 2-1/4 |
| AN6227B-32 | MS28775-329 | 3/16 | 2 | 2-3/8 |
| AN6227B-33 | MS28775-330 | 3/16 | 2-1/8 | 2-1/2 |
| AN6227B-34 | MS28775-331 | 3/16 | 2-1/4 | 2-5/8 |
| AN6227B-35 | MS28775-332 | 3/16 | 2-3/8 | 2-3/4 |
| AN6227B-36 | MS28775-333 | 3/16 | 2-1/2 | 2-7/8 |
| AN6227B-38 | MS28775-335 | 3/16 | 2-3/4 | 3-1/8 |
| AN6227B-39 | MS28775-336 | 3/16 | 2-7/8 | 3-1/4 |
| AN6227B-40 | MS28775-337 | 3/16 | 3 | 3-3/8 |
| AN6227B-41 | MS28775-338 | 3/16 | 3-1/8 | 3-1/2 |
| AN6227B-42 | MS28775-339 | 3/16 | 3-1/4 | 3-5/8 |
| AN6227B-43 | MS28775-340 | 3/16 | 3-3/8 | 3-3/4 |
| AN6227B-44 | MS28775-341 | 3/16 | 3-1/2 | 3-7/8 |
| AN6227B-45 | MS28775-342 | 3/16 | 3-5/8 | 4 |
| AN6227B-46 | MS28775-343 | 3-16 | 3-3/4 | 4-1/8 |
Q+A
Can these O rings be used in fuel cells with 100LL fuel?
These o-rings, AN6227B series, are not fuel resistant. For fuel resistant o-rings, see the MS29513 series. MS29513 are aviation fuel resistant, but not resistant to automotive fuel. Search for MS29513 on our web site to find the page with the fuel resistant o-rings.
| Unit | EA |
| Hazardous | No |
| Oversize | No |
| Weight | 0.002 kg |
| Manufacturer | |
| Manufacturer P/N | |
| GTIN | |
| Core Charge | Yes (add to cart to see price) |
| 110V device | Yes |
