Ideal for use in installations of Garmin devices, the ZFSC-2-1B is a coaxial power splitter and/or combiner available at an excellent price point that is identical to Garmins part number 013-00112-00. The ZFSC-2-1B can be used in VHF and UHF applications, instrumentation, and communication systems.

• Wideband, 5 to 500 MHz
• Low insertion loss, 0.3 dB typ.
• Excellent isolation, 28 dB typ.
• Excellent amplitude unbalance, 0.1 dB typ.
• Good VSWR, 1.2:1 typ.
• Rugged shielded case
• For use in VHF/UHF, instrumentation, and communication systems
• RoHS compliant in accordance with EU Directive (2002/95/EC)

• Weight: 70 grams
• Dimensions: 2.18 x 0.75 in
• Frequency: 5 - 500 MHz
• Impedance: 50 ohm
• Maximum ratings: operating temperature: -55C to 100C
• storage temperature: -55 to 100C
• power input (as a splitter): 1W max.
• Coaxial connections: SUM port: 3, port 1: 1, port 2: 2
