MGL V6R REMOTE VHF COM

The V6R is the remote version of the popular V6 Radio. It is identical to the V6 radio with the exception of the face and front controls. It requires either an MGL Avionics iEFIS, Odyssey/Voyager or R2 Control Head to function.

Based on the digital technology intruduced in the V10, the V6R provides the same powerful 6W transmitter and modulation system. Designed for 25Khz spacing with 8.33Khz compatible operation selectable, the dual scan receiver boasts the fastest scanning time which means no loss of reception quality during receive of the standby channel.

100 channel storage and channel operating mode compatible with the V10. Four place, dual circuit intercom system with full isolate. Each intercom microphone input has its own level control and VOGAD noise suppression system. Dual PTT inputs. Black box flight recorder audio output.

The intercom outputs are fully stereo with a dedicated stereo music input plus two auxiliary channels for mobile phone and EFIS annunciators.
The V6R has a wide operating voltage range: 12V to 28V DC

• Small Size: The V6R can easily mount behind the panel.
• Remote: The V6R can be fully remote-controlled by an MGL Avionics iEFIS (or Odyssey/Voyager) or the upcoming R2 Control head, so you can mount it remotely, out of the panel and away from sensitive avionics. It can be controlled by 2 control devices - any combination of iEFIS units or R2 Control heads.
• Full Stereo: The V6R features a stereo intercom that allows you to listen to stereo music if you connect a music player to the aux audio input (requires stereo headsets). Music automatically mutes down on receive/transmit. There are also 2 mono audio inputs for EFIS alarm annunciator and phone connection.
• 4 Microphone Channels: The V6R has 4 individual microphone channels for independent level/VOGAD settings for each mic in a 4-place aircraft.
• Independent Radio/Intercom Volume controls: The V6R allows you to ‘turn down’ the radio volume while keeping the intercom volume high, for use in busy radio environments.
• Isolate Modes: Flying a 4-place aircraft and want to let your 3 passengers (or your 2 backseat passengers) talk amongst themselves while you do the hard work up front? Select one of the V6 isolate modes.

• Small Size: The V6R has a mounting height of only 4.2” + connectors! You can mount it in any orientation.
• Light Weight: Approximately 8.8 oz (about 0.5 lb). One of the lightest out there - great when every ounce counts!
• Powerful: 6 full Watts of transmit power. Huge power for a small package.
• Digital Interface: Full Remote Control functionality allows interface with third party devices.
• Built-in VOX / VOGAD Intercom: The V6R features a high quality intercom system (not a ‘hot mic’ - this intercom is really usable as your primary intercom!). The intercom has 4 independent microphone channels. There are several modes of operation for the intercom, including VOX options and MGL Avionics’ proprietary VOGAD system. VOGAD (or voice-operated gain-adjusting device) works by adjusting the gain of the microphone as your speak based on the level of your voice. This has the effect of eliminating background/engine noise between your words as you speak and can be used with simple passive headsets to produce the results normally obtained using expensive active noise cancelling headsets. It doesn’t ‘break squelch’ like a VOX intercom - it is activated by your voice and is constantly adjusting to your voice level.
